EVERCROSS BRIDGE TECHNOLOGY (SHANGHAI) CO.,LTD.
About Us
Your Professional & Reliable Partner.
Production Factory:Total Area: 47,000㎡Production workshop: 22,000㎡Lifting Capacity:100 tonsAnnual output:100,000 tonsMain Products:Bailey bridge(Compact-200, Compact-100, LSB, PB100, China-321,BSB)Modular bridge( GWD, Delta, 450-type,etc),Truss Bridge,Warren bridge,Arch bridge, Plate bridge,Beam bridge,Box girder bridge,Suspension bridge,Cable-stayed bridge,Floating bridge,etcCertificates:ISO9001, ISO14001,ISO45001,EN1090,CIDB,COC,PVOC,SONCAP,etcExperience:40 sets of Bailey bridges to Colombia ...
Learn More

0

Year Established

0

Million+
Employees

0

Million+
Annual Sales
China EVERCROSS BRIDGE TECHNOLOGY (SHANGHAI) CO.,LTD. HIGH QUALITY
Trust Seal, Credit Check, RoSH and Supplier Capability Assessment. company has strictly quality control system and professional test lab.
China EVERCROSS BRIDGE TECHNOLOGY (SHANGHAI) CO.,LTD. DEVELOPMENT
Internal professional design team and advanced machinery workshop. We can cooperate to develop the products you need.
China EVERCROSS BRIDGE TECHNOLOGY (SHANGHAI) CO.,LTD. MANUFACTURING
Advanced automatic machines, strictly process control system. We can manufacture all the Electrical terminals beyond your demand.
China EVERCROSS BRIDGE TECHNOLOGY (SHANGHAI) CO.,LTD. 100% SERVICE
Bulk and customized small packaging, FOB, CIF, DDU and DDP. Let us help you find the best solution for all your concerns.

quality Steel Bailey Bridge & Modular Steel Bridge manufacturer

Find Products That Better Meet Your Requirements.
Cases & News
The Latest Hot Spots.
Do you know the role of steel box girders in bridge construction?
If you've ever marveled at the sleek elegance of a long-span bridge arching over a valley or stretching across a wide river, chances are you've witnessed the silent power of the steel box beam. This unassuming structural element, essentially a hollow rectangular or trapezoidal tube fabricated from high-strength steel plates, is a cornerstone of modern bridge engineering. Its unique properties make it indispensable for tackling the demanding challenges faced by infrastructure developers, particularly in the sophisticated markets of Europe and North America. I. Demystifying the Steel Box Beam: Form and Function At its core, a steel box beam is a closed-section structural member. Imagine a rectangular tube, often wider than it is tall, formed by welding together four steel plates (top flange, bottom flange, and two webs). Variations include trapezoidal boxes (offering slightly different aerodynamic and structural benefits) and multi-cellular boxes for exceptionally large bridges. This hollow design is key to its success: High Strength-to-Weight Ratio: Steel provides immense strength, while the hollow section minimizes dead weight. This is crucial for long spans where the bridge's own weight is a major design factor. Lighter structures mean smaller, more economical foundations and supporting piers. Exceptional Torsional Rigidity: The closed box shape resists twisting forces (torsion) far more effectively than open sections like I-beams. This is vital for bridges carrying heavy, eccentric loads (like multiple lanes of traffic) or those subjected to strong winds or seismic activity. Efficient Load Distribution: The continuous top and bottom flanges provide excellent pathways for distributing bending stresses (compression on top, tension on the bottom) across the entire cross-section. The webs efficiently transfer shear forces. Aerodynamic Stability: The smooth, enclosed shape offers inherent aerodynamic advantages. It minimizes wind drag and, crucially, is far less susceptible to dangerous wind-induced oscillations (like the infamous Tacoma Narrows failure) compared to open truss sections. This makes it ideal for tall piers and long spans exposed to high winds. Versatility in Construction: Box beams can be prefabricated in controlled factory conditions, ensuring high quality and dimensional accuracy. They can then be transported to site in large segments for efficient erection – a significant advantage in minimizing traffic disruption or working in challenging environments (over rivers, gorges, or existing infrastructure). II. The Evolution of the Steel Box Beam: From Concept to Cornerstone While the basic principle of a beam has ancient roots, the modern steel box beam emerged and evolved significantly throughout the 20th century, driven by advancements in materials, fabrication techniques, and engineering understanding: Early Pioneering (Pre-WWII): Initial uses were often in buildings or shorter bridges, limited by steel quality and welding technology. Riveted construction was common. Post-War Advancements (1940s-1960s): The development of high-strength, weldable steels (like ASTM A572, A709 grades) and reliable arc welding techniques revolutionized box girder construction. Iconic early examples include the Mangfall Bridge in Germany (1959) and the Severn Bridge in the UK (1966), which demonstrated the potential for longer spans. Learning from Setbacks: The partial collapse of the Cleddau Bridge in Wales (1970) and the Rhine Bridge at Koblenz (1971) during construction highlighted critical issues with buckling in thin-walled box sections under complex stresses. These tragedies, while devastating, led to profound advancements in understanding plate stability, buckling behavior, and design codes worldwide (e.g., Eurocode 3, AASHTO LRFD specifications). Modern Refinement (1970s-Present): Enhanced computational power (Finite Element Analysis - FEA) allows for incredibly sophisticated modeling of complex stresses and behaviors. Improved fabrication methods (automated welding, precision cutting) ensure higher quality and consistency. Corrosion protection systems (high-performance coatings, dehumidification systems inside boxes) have dramatically extended service life. Aerodynamic tuning (adding fairings, modifying cross-section shapes) further optimizes performance. III. Steel Box Beams in Action: Dominating European and American Landscapes The inherent advantages of steel box beams align perfectly with the infrastructure demands of Europe and North America: the need for durable, long-span solutions that minimize environmental impact and construction disruption. They are the go-to choice for: Long-Span Bridges: Cable-Stayed Bridges: Box beams form the stiff, aerodynamic decks of most major cable-stayed bridges. Examples abound: France's iconic Millau Viaduct (world's tallest bridge, features a streamlined trapezoidal steel box deck), the UK's Second Severn Crossing, Denmark's Great Belt East Bridge, and the USA's Arthur Ravenel Jr. Bridge (Charleston, SC). The torsional rigidity is essential for handling the concentrated forces from the stay cables. Suspension Bridges: While suspension bridges often use truss decks for very long spans, steel box girders are increasingly favored for their superior aerodynamics and lighter weight. The Humber Bridge (UK) and the Storebælt East Bridge (Denmark) are prime examples. The Tacoma Narrows replacement bridge famously switched from trusses to a stiffening box girder after the original's collapse. Viaducts and Elevated Highways: The efficiency of prefabrication and erection makes box beams ideal for long viaducts crossing varied terrain. Spain's extensive high-speed rail network features countless steel box viaducts. In the US, projects like the I-35W St. Anthony Falls Bridge (Minneapolis) utilized large steel box segments for rapid reconstruction. Curved Bridges: The inherent torsional stiffness of the box section makes it exceptionally well-suited for bridges with significant horizontal curvature, a common requirement in complex urban interchanges or mountainous terrain. The Leonard P. Zakim Bunker Hill Bridge (Boston, USA) is a stunning cable-stayed example with a highly curved deck built using steel box segments. Rail Bridges: The stiffness and durability of steel box girders are crucial for handling the dynamic loads and stringent deflection limits of high-speed rail lines, prevalent across Europe (e.g., numerous bridges on France's TGV lines, Germany's ICE network) and increasingly in North American projects. IV. The Indispensable Role: Why Steel Box Beams are Engineering Heroes Steel box beams deliver tangible, critical benefits that directly address the core challenges of modern bridge construction: Enabling Record Spans: Their strength and lightness allow engineers to bridge wider gaps with fewer supports, minimizing environmental impact in sensitive areas (rivers, valleys, wetlands) and reducing costs associated with deep foundations and numerous piers. Conquering Complex Loads & Environments: Their torsional rigidity handles eccentric traffic, wind, and seismic forces reliably. Superior aerodynamics ensure stability even in extreme wind conditions common on tall bridges or coastal locations. High-grade steels and protection systems combat corrosion effectively.Accelerating Construction: Factory fabrication ensures quality control and allows work to proceed regardless of weather. Large segments can be lifted into place rapidly using heavy-lift equipment (cranes, launching gantries, barges), dramatically reducing on-site construction time and associated traffic delays or community disruption – a major factor in densely populated Europe and America.Optimizing Life-Cycle Costs: While initial material costs might be higher than concrete in some cases, the benefits often outweigh this: faster construction reduces financing and traffic management costs, lighter weight reduces foundation costs, durability and easier inspection/access for maintenance (thanks to the enclosed space) lead to lower long-term upkeep expenses. Architectural Versatility: The clean lines of a steel box girder deck offer a modern, aesthetically pleasing appearance. Its form can be subtly shaped (e.g., varying depth, adding fairings) to enhance both function and visual appeal, contributing positively to the urban or natural landscape. The Enduring Pillar of Progress The steel box beam is far more than just a component; it is an enabling technology that has reshaped the possibilities of bridge engineering. Its evolution, marked by both innovation and lessons learned, has cemented its status as the premier solution for ambitious infrastructure projects demanding long spans, resilience against complex forces, rapid construction, and long-term durability. In the demanding markets of Europe and North America, where efficiency, environmental sensitivity, and structural performance are paramount, the steel box beam continues to be the unseen backbone supporting the arteries of modern transportation. As bridge designs push further boundaries – spanning wider estuaries, integrating smarter materials, adapting to climate challenges – the inherent strengths and adaptability of the steel box beam ensure it will remain a fundamental force in building the resilient and connected infrastructure of tomorrow. For the discerning buyer or engineer in the global marketplace, understanding the pivotal role of this remarkable structure is key to appreciating the true value and capability embedded in modern steel bridge solutions.

2025

06/17

Do you know Bailey bridge which Reshaped America’s Infrastructure in WWII Innovation ?
What is Bailey Bridge? In 1941, as Britain endured relentless aerial attacks during World War II, civil engineer Sir Donald Bailey sketched a revolutionary idea on the back of an envelope: a modular steel bridge that could be assembled by hand, without cranes, using interchangeable parts. His design solved three critical wartime challenges: Speed: Rapid assembly (as little as 6 hours). Adaptability: Configurable for spans up to 200+ feet and load capacities exceeding 80 tons. Portability: Components light enough for soldiers to carry (largest part: 600 lbs). By 1942, Bailey Bridges were deployed across Europe and North Africa, becoming the "Lifelines of Liberation" for Allied forces. Churchill praised them as "the war-winning invention no one noticed." Crossing the Atlantic: Bailey Bridges in America The U.S. Army Corps of Engineers recognized the Bailey’s potential in 1942. But true to American ingenuity, they didn’t just adopt it—they reinvented it: Material Innovation: Replaced British mild steel with high-tensile ASTM A709 steel, boosting strength-to-weight ratios. Component Standardization: Refined panel pins, transoms, and decking for faster assembly. Civilian-Military Synergy: Firms like Acrow Corporation (founded 1941) licensed designs to mass-produce bridges for both D-Day and U.S. infrastructure. The iconic "American Bailey" emerged—lighter, stronger, and optimized for railroads and heavy logistics. America’s First Bailey Bridge: Fort Belvoir, Virginia (1942) In a watershed moment, the first U.S.-assembled Bailey Bridge was erected at Fort Belvoir’s Engineer School in 1942. Its impact was immediate: Strategic Training Hub: Used to train 20,000+ combat engineers for WWII campaigns. Proof of Concept: Demonstrated assembly by 12 soldiers in 32 hours—beating British records. Technical Legacy: Refined U.S. variants like the "Callender-Hamilton Bridge" drew direct inspiration. The bridge became a symbol of "Yankee improvisation," blending British genius with American industrial pragmatism. Transforming American Infrastructure Bailey Bridges didn’t just serve the military—they reshaped America’s civilian landscape: Disaster Response: Deployed during the 1948 Columbia River floods (Oregon) and 1955 Hurricane Diane (Northeast). Rail Revolution: Enabled temporary rail diversions for projects like the Chesapeake Bay Bridge-Tunnel (1960s). Rural Access: Provided critical links for Appalachian mining towns and Alaskan frontier communities. By 1970, over 15,000 Bailey variants spanned U.S. rivers, canyons, and construction sites. Engineering Legacy: Where Innovation Meets Endurance Today’s modular bridges—from Acrow’s 1000XS to Mabey’s Compact 200®—owe their DNA to Bailey’s 1941 sketch. Key evolutions include: Feature Original Bailey (UK) American Evolution Material Mild Steel High-Tensile ASTM Steel Span Range 10–200 ft 10–500+ ft Max Load Class 40 (40 tons) MLC 150 (150+ tons) Assembly Time 24–72 hours 6–12 hours (with cranes) The Bridge That Built the Future The Bailey Bridge’s legacy endures in unexpected ways: Military Doctrine: U.S. Army’s Medium Girder Bridge (MGB) system is a direct descendant. Space-Age Spin-offs: NASA’s modular launch structures applied Bailey-style engineering. Global Standards: Eurocode-compliant variants now serve in 150+ countries. When a Bailey Bridge reopened flood-ravaged Yellowstone in 2022, it proved that 80-year-old innovation still outpaces modern crises. More Than Steel—A Symbol of Resilience From Fort Belvoir’s training grounds to Ukraine’s battlefields today, the Bailey Bridge remains a testament to modular design’s timeless power. For America, it was more than a wartime tool—it was a steel symphony of speed, strength, and ingenuity that redefined how nations build and rebuild. As you operate in the global steel bridge arena, remember: you’re not just trading components—you’re extending a legacy that connects worlds.

2025

06/16

Trestle Bridges: The Enduring Framework of Railroads, Construction, and Infrastructure
Unlike the standardized modularity of the Bailey bridge, the trestle bridge represents a fundamental and ancient structural concept defined by its distinctive framework: a series of short spans supported by rigid, vertical or slightly inclined towers (bents) connected at the top by longitudinal stringers or girders. This simple yet robust design has shaped landscapes, enabled industrial expansion, and remains vital in construction and transportation. Defining the Trestle: A Framework Over Obstacles At its core, a trestle bridge is a viaduct built upon a repeating series of bents. Each bent typically consists of: Posts/Piles: Vertical or slightly battered (inclined) structural members carrying the primary load downwards. These can be timber, steel, or concrete. Caps/Cap Beams: Horizontal beams connecting the tops of the posts/piles within a single bent, distributing loads across them. Bracing: Diagonal or horizontal members connecting posts within a bent and often between adjacent bents, providing critical stability against lateral forces (wind, seismic activity, train sway) and preventing buckling. The deck (carrying the roadway or railway tracks) rests directly on stringers or girders that span between the cap beams of adjacent bents. This creates a series of short spans over the supporting framework. Key characteristics: Adaptability to Terrain: Excels in crossing uneven ground, deep ravines, valleys, floodplains, or marshy areas where building continuous embankments is impractical or too expensive. Material Versatility: Historically timber, now predominantly steel or concrete. Viaduct Form: Often used for elevated crossings over long distances or significant depths. Open Structure: Allows light and water (or even small debris) to pass beneath, reducing wind load and sometimes environmental impact compared to solid embankments. A History Rooted in Timber and Rails The trestle bridge concept is ancient, but its most iconic and transformative era began with the explosive growth of railroads in the 19th century, particularly in North America: Timber Trestle Dominance (Mid-Late 1800s): Abundance: Timber was readily available, relatively inexpensive, and easy to work with using basic tools. Rapid Construction: Enabled railroads to push rapidly across continents, conquering challenging terrain like the American West and Canadian wilderness much faster than building solid earthworks. Iconic Structures: Massive timber trestles became landmarks (e.g., the original Starrucca Viaduct, though later rebuilt in stone, and countless others). They embodied the daring engineering of the railroad era. Limitations: Vulnerable to fire, rot, insect damage, and required significant maintenance. Load capacity was limited compared to later materials. Transition to Steel and Concrete (Late 1800s - Present): Steel Trestles: Offered vastly superior strength, longer lifespan, greater fire resistance, and higher load capacity (essential for heavier locomotives and freight). Steel bents with lattice or rolled beam components became standard for major railroad crossings and later highways. Steel is also the primary material for temporary construction trestles. Concrete Trestles: Provide excellent durability, fire resistance, and minimal maintenance. Often used for permanent highway viaducts and modern rail lines. Can be cast-in-place or use precast elements. Materials: From Timber to Modern Composites The evolution of materials defines the trestle bridge's history and applications: Timber: Traditional: Heavy timber (often treated hardwoods like oak or treated softwoods) for posts, caps, bracing, and deck stringers. Modern: Engineered wood products (glulam beams, LVL) are sometimes used for specific components in permanent or temporary structures, offering improved strength and consistency. Use: Primarily historical preservation, light-duty applications, temporary work trestles (less common now), or in areas with abundant sustainable timber resources. Steel: Structural Shapes: Rolled wide-flange beams (I-beams), channels, and angles are common for posts, caps, stringers, and bracing. Fabricated Sections: Built-up box sections or plate girders for heavy loads or long spans between bents. Piling: Steel H-piles or pipe piles driven into the ground for foundation support. Corrosion Protection: Priming, painting, and increasingly, hot-dip galvanizing are essential for longevity. Use: The dominant material for permanent railroad trestles, major highway viaducts, and almost all heavy-duty temporary construction trestles. Concrete: Reinforced Concrete (RC): Standard for cast-in-place bents, caps, and decks. Precast/Prestressed Concrete: Precast bent caps, columns, or full bents are common for faster construction. Prestressed concrete girders span between bents. Use: Widely used for permanent highway overpasses, viaducts in urban areas, and modern rail corridors due to durability and low maintenance. Construction and Applications: Beyond the Rails Trestle bridge construction varies significantly based on permanence and material: Permanent Trestles (Rail & Road): Foundation: Requires deep, stable foundations (driven piles, drilled shafts, spread footings) depending on soil conditions and load. Erection: Cranes lift prefabricated steel bents or place reinforcing steel and formwork for concrete pours. Girders/stringers are then placed. Railroads: Remain absolutely critical for crossing valleys, canyons, and floodplains. Modern examples are almost exclusively steel or concrete. (e.g., the massive steel trestles traversing mountain passes). Highways: Used for elevated expressways through cities, crossing valleys or waterways where a solid embankment isn't feasible (e.g., many viaducts in highway systems). Temporary Construction Trestles: Material: Almost exclusively steel, designed for modularity, reusability, and rapid assembly/disassembly. Purpose: Provide temporary elevated work platforms and support for: Building permanent bridges (supporting falsework, formwork, and equipment). Dam construction/repair. Pipeline or cable installation over obstacles. Providing access in difficult terrain for various construction projects. Components: Standardized steel frames (bents), braces, stringers, and decking (often timber planks or steel grating). Designed for specific load capacities (workers, equipment, materials). Assembly: Typically assembled piece-by-piece with bolts or pins using cranes or derricks. Safety and stability under dynamic construction loads are paramount. Iconic Examples and Enduring Relevance Lethbridge Viaduct (Alberta, Canada): One of the world's longest and highest steel trestle bridges, carrying the Canadian Pacific Railway across the Oldman River valley (1.6km long, 96m high). Goat Canyon Trestle (California, USA): A massive, isolated timber trestle (now largely collapsed), a relic of the daring railway construction era. Numerous Highway Viaducts: Elevated sections of interstates and other highways crossing urban areas or valleys often utilize concrete or steel trestle designs. The trestle bridge, from its humble timber origins powering the railroad revolution to the massive steel and concrete viaducts of today, is a testament to the enduring power of a simple structural concept. Defined by its repetitive bents and short spans, it solves the fundamental problem of traversing uneven or obstructed terrain efficiently. While sharing the goal of crossing obstacles with the Bailey bridge, the trestle achieves it through a fundamentally different structural approach – a rigid, often permanent framework rather than a modular, rapidly deployable truss. Its evolution from wood to steel and concrete mirrors advances in engineering and materials science. Whether carrying mile-long freight trains across mountain chasms, supporting elevated highways through cities, or providing the essential backbone for constructing other major infrastructure, the trestle bridge remains an indispensable and iconic element of our built environment. Its framework continues to shape skylines and conquer challenging landscapes.
