Product Name: |
Ultra-Thin Steel Structure Fireproof Coating |
Coating Thickness: |
Each Spray Coat 1~3mm |
Grade: |
Grade A |
PH Value: |
Greater Than 7 |
Specification: |
Customizable |
Product Name: |
Ultra-Thin Steel Structure Fireproof Coating |
Coating Thickness: |
Each Spray Coat 1~3mm |
Grade: |
Grade A |
PH Value: |
Greater Than 7 |
Specification: |
Customizable |
Water-based intumescent fire resistive coating Description:
Water-based intumescent fire resistive coating for steel structure
Ultra-thin steel structure fireproof coatings are specialized intumescent paint-like materials applied to the surface of steel structural members to provide fire resistance. These coatings expand and char when exposed to high temperatures, creating an insulating layer that protects the underlying steel from rapid heating and loss of structural integrity during a fire.
The ultra-thin steel structure fireproof coating produced by our company has the following characteristics:
1. Excellent fire performance: the coating can expand rapidly when heated by fire, forming a solid refractory heat insulation barrier, with thin coating, high foaming rate, the formation of heat insulation bubble layer uniform and dense characteristics. Less than a millimeter of coating can expand into nearly 20 millimeters of foam insulation, and the uniform dense carbon layer increases the fire resistance of the steel structure.
2. Excellent environmental performance: the coating has the characteristics of high solid content and low VOC content, solid content up to 75%, small volatile amount of organic matter, environmental protection and safety, suitable for use in closed environments such as building rooms and ship cabins. The paint with water as the solvent, less volatile organic matter, low environmental pollution, to overcome the oil-based fireproof paint flammable and explosive, toxicity, transportation, storage and use of unsafe shortcomings, is conducive to environmental protection and production, construction personnel health and safety.
3. Excellent coating performance: The coating has the advantages of easy coating and strong adhesion while having high solid content.
4. Ultra-thin coating; reducing the load weight under the premise of ensuring the fire protection effect is of great significance in the field of aviation and aerospace, as well as in the use of ships and key parts.
| GT-NSP-Fp2.50-1C-HG Comparison of physical and chemical properties of fireproof coatings for indoor expanded steel structures | |||||
| No. | Physical and chemical properties | GB14907-2018 | Q/ HG001-2023 | Test report | Defect class |
| 1 | The state in the container | After stirring, it is in a uniform and fine state or a thick and thick fluid state, without agglomeration | Uniform and fine, no clumps | C | |
| 2 | Drying time (surface dry)/h | ≤12 | ≤8 | ≤5 | C |
| 3 | Initial drying resistance to cracking | Should not be cracks | No crack | C | |
| 4 | Bond strength /MPa | ≥0.15 | ≥0.20 | ≥0.39 | A |
| 5 | Compressive strength /MPa | C | |||
| 6 | Dry density /(kg/ m ³) | C | |||
| 7 | Thermal insulation efficiency deviation | ±15% | 一 | ||
| 8 | PH Value | ≥ 7 | ≥ 8.23 | C | |
| 9 | Water resistance | After 24h test, the coating should have no lamination, foaming, falling off phenomenon, and the heat insulation efficiency attenuation should be less than 35% | No layer, foaming, falling off phenomenon, heat insulation efficiency attenuation Less than or equal to 35% | A | |
| 10 | Resistance to hot and cold cycling | After 15 times tests, the coating should have no cracking, peeling, foaming phenomenon, and the heat insulation efficiency attenuation should be less than 35% | No cracking, peeling, foaming phenomenon, heat insulation efficiency attenuation Less than or equal to 35% | B | |
| Note 1:A is a fatal defect, B is a serious defect, C is a minor defect; - indicates that there is no requirement. Note 2: Thermal insulation efficiency deviation is only used as a factory inspection item. Note 3: pH value is only applicable to water-based steel structure fire retardant coatings. |
|||||
| GT-NSP-Fp2.50-1C-HG, means indoor water-based expansion type ordinary steel structure fireproof coating, the fire resistance is Fp2.50, the coating thickness is 1.5mm Less than or equal to 2mm user-defined code HG. | |||||
Applications of ultra-thin steel structure fireproof coatings:
High-rise buildings and skyscrapers
Industrial facilities and warehouses
Transportation infrastructure (bridges, tunnels)
Evercross Steel Bridges Overview:
| EVERCROSS STEEL BRIDGE SPECIFICATION | |
| EVERCROSS STEEL BRIDGE |
Bailey bridge (Compact-200, Compact-100, LSB, PB100, China-321, BSB) Modular bridge (GWD, Delta, 450-type, etc.), Truss Bridge, Warren bridge, Arch bridge, Plate bridge, Beam bridge, Box girder bridge, Suspension bridge, Cable-stayed bridge, Floating bridge, etc. |
| DESIGN SPANS | 10M TO 300M Single span |
| CARRIAGE WAY | SINGLE LANE, DOUBLE LANES, MULTILANE, WALKWAY, ETC |
| LOADING CAPACITY | AASHTO HL93.HS15-44, HS20-44, HS25-44, BS5400 HA+20HB, HA+30HB, AS5100 Truck-T44, IRC 70R Class A/B, NATO STANAG MLC80/MLC110. Truck-60T, Trailer-80/100Ton, etc. |
| STEEL GRADE | EN10025 S355JR S355J0/EN10219 S460J0/EN10113 S460N/BS4360 Grade 55C AS/NZS3678/3679/1163/Grade 350, ASTM A572/A572M GR50/GR65 GB1591 GB355B/C/D/460C, etc. |
| CERTIFICATES | ISO9001, ISO14001, ISO45001, EN1090, CIDB, COC, PVOC, SONCAP, etc. |
| WELDING | AWS D1.1/AWS D1.5 AS/NZS 1554 or equivalent |
| BOLTS | ISO898, AS/NZS1252, BS3692 or equivalent |
| GALVANIZATION CODE | ISO1461 AS/NZS 4680 ASTM-A123, BS1706 or equivalent |
